Dongguan Zhiling Motor Technology Co., Ltd.
3 Years
| Ask Lasest Price | |
| Brand Name : | Aidecoolr |
| Model Number : | BF5015 |
| Supply Ability : | 3000000 Piece/Pieces per Month |
| Price : | $1.80/pieces 1000-2999 pieces |
Dimensions:
Based on the information provided by the link you shared, the product appears to be a small blower fan with dimensions of 50x50x15mm, designed for use in bidets, air purifiers, and 3D printers.
The compact size and efficient design make it ideal for use in applications where space is limited and noise reduction is important.
The product is made from durable materials and is designed to be easy to install.
Overall, if you are in need of a small blower fan to help improve the cooling performance or airflow in your bidet, air purifier, or 3D printer, this product might be worth considering.
However, it's important to do your own research and make sure that this product is compatible with your specific hardware and voltage requirements before making a purchase.
Parameters:
| Model | Bearing Type | Rated Voltage | operation Voltage | Current | lnput Power | Speed | AirFlow | Static Pressure | Noise Level |
| vDc | vDc | Amp | Watt | RPM | CFM | MM-HO | dBA | ||
| BF5015L12S | Sleeve | 12v | 10.8~13.2 | 0.03 | 0.36 | 3,000±10% | 2.30 | 4.00 | 25.0 |
| BF5015L12D | 2-Bali | ||||||||
| BF5015L12SH | Hydraulic | ||||||||
| BF5015M12S | Sleeve | 12V | 10.813.2 | 0.06 | 0.72 | 4,000±10% | 7.40 | 31.0 | |
| BF5015M12D | 2Ball | ||||||||
| BF5015M12SH | Hydraulic | ||||||||
| BF5015H12S | Sleeve | 12v | 10.8~13.2 | 0.10 | 1.20 | 5.000±10% | 10.4 | 38.5 | |
| BFS015H12D | 2-Ball | ||||||||
| BF5015H12SH | Hydraulic | ||||||||
| BF5015L24S | Sleeve | 24V | 21.6~26.4 | 0.02 | 0.48 | 3,000+10% | 4.00 | 25.0 | |
| BF5015L24D | 2Ball | ||||||||
| BF5015L24SH | Hydraulic | ||||||||
| BF5015M24s | Sleeve | 24V | 21.6~26.4 | 0.04 | 0.96 | 4,000±10% | 3.00 | 7.40 | 31.0 |
| BF5015M24D | 2-Ball | ||||||||
| BF5015M24SH | Hydraulic | ||||||||
| BF5015H24S | Sleeve | 24V | 21.6~26.4 | 0.06 | 1.44 | 5,000±10% | 10.4 | 38.5 | |
| BF5015H24D | 2-Ball | ||||||||
| BF5015H24SH | Hydraulic |
Parts Specs: | P&Q Curve | |
Bearing type:Sleeve,2-Ball,Hydraulic Material: 5V,12V,24V are available |  |
Electrical Specifications:
| Insulation Resistance | 10MΩ/between unshackled wire and frame at 500VDC/min |
| Dielectric Strength | 5Ma Max./Measured between lead wire(+)and frame at 500VAC/min |
| Rotating Direction | Anti-Clockwise |
| Polarity Protect | Circuit is protected when VCC&GND are exchanged |
| No. of pole | 4Poles |
Environmental Specifications
| Operating Temp Range | Temperature:-10℃~+70℃ Humidity:35%~85%RH |
| Store Temperature | Temperature:-40℃~+70℃ Humidity:35%~85%RH |
| Thermal Shock | Standard:MIL-STD 202F Method 107D,Condition D |
| Insulation Shock | UL:Class A |
| FCL Shipment | LCL Shipment | |
 |  |
Air shipment:
Lifetime:
| Bearing type | Lifetime |
| Sleeve | 30,000 hours |
| Hydraulic | 40,000 hours |
| 2-Ball | 60,000 hours |
|
|
